PRODUCTS
Product Details
Hastelloy G-30
Hastelloy G-30 is a nickel-chromium alloy offering excellent corrosion resistance in phosphoric acid, sulfuric acid, oxidizing environments, and demanding chemical processing applications.
.png)
Category
Nickel Alloy
.png)
Grade
Hastelloy G-30 / UNS N06030 / 2.4603
.png)
Standard
.png)
Product Form
ASTM B582 / B581 / B622 / B619 / B626 / B366 / B564
Plate / Sheet / Strip / Bar / Wire / Pipe / Tube / Forgings / Fittings
.png)
Thickness
0.5–100 mm
.png)
Width
1000–2500 mm
.png)
Length
2000–6000 mm
Features
Hastelloy G-30 is a high-chromium nickel-based corrosion-resistant alloy developed to provide excellent performance in strongly oxidizing environments. It is particularly effective in phosphoric acid service, including industrial acid streams containing chlorides, fluorides and other impurities.
Its combination of chromium, molybdenum and tungsten provides broad resistance to aggressive chemical media, while the relatively high chromium content contributes strong resistance to oxidizing acids. The alloy also provides good resistance to localized corrosion and stress corrosion cracking.
Hastelloy G-30 is well suited for demanding chemical-processing equipment, including heat exchangers, process piping, vessels and components used in phosphoric acid and fertilizer production.
Surface Finish | Pickled / Bright / Ground / Polished / Machined |
Technique | Hot Rolled / Cold Rolled / Forged / Welded / Seamless / Solution Annealed |
Applications | Phosphoric Acid Production, Chemical Processing, Fertilizer Equipment, Heat Exchangers, Process Piping, Acid Handling Systems |
Excellent resistance to phosphoric acid
Strong resistance to oxidizing environments
Good resistance to sulfuric acid
Excellent resistance to localized corrosion
Good resistance to chloride-containing media
Suitable for contaminated industrial acid streams
Good fabrication and welding characteristics
Designed for severe chemical-processing service
Chemical Composition (%)
Mechanical Properties (Typical)
Element | Composition (%) |
Ni | Balance |
Cr | 28.0–31.5 |
Fe | 13.0–17.0 |
Mo | 4.0–6.0 |
W | 1.5–4.0 |
Co | ≤ 5.0 |
Cu | 1.0–2.4 |
Nb | 0.3–1.5 |
Mn | ≤ 1.5 |
Si | ≤ 0.8 |
C | ≤ 0.03 |
P | ≤ 0.04 |
S | ≤ 0.02 |
Property | Typical Value |
Tensile Strength | Approx. 585–690 MPa |
Yield Strength (0.2%) | Approx. 240–310 MPa |
Elongation | Approx. 40–50% |
Density | Approx. 8.22 g/cm³ |
Mechanical properties may vary depending on product form, dimensions, processing condition, and applicable material specification.
