Monel 400

Product Details

Monel 400

Monel 400 is a nickel-copper alloy offering excellent corrosion resistance, good mechanical strength, and reliable performance in marine, chemical processing, and industrial environments.

9e7165ffd77fb83ebbaeb46de2c81238 (1).png

Category

Nickel Alloy

微信图片_20260816164737_202_2 (1).png

Grade

Monel 400 / UNS N04400 / 2.4360

85283eccd1d5a7291920c84b40d1a3ae (1).png

Standard

微信图片_20260816165015_204_2 (1).png

Product Form

ASTM B127 / ASTM B164 / ASTM B165 / ASTM B730

Plate / Sheet / Strip / Bar / Rod / Pipe / Tube / Wire / Forging

微信图片_20260816165038_205_2 (1).png

Thickness

0.5–100 mm

微信图片_20260816165049_206_2 (1).png

Width

1000–2500 mm

微信图片_20260816165104_207_2 (1).png

Length

2000–6000 mm

Features

Monel 400 is a solid-solution nickel-copper alloy known for its excellent corrosion resistance, good mechanical strength and toughness. Its high nickel content provides reliable performance in a wide range of corrosive environments, while the copper content contributes to its resistance in marine and chemical service.

The alloy offers particularly good resistance to flowing seawater and many neutral and reducing media. It also performs well in various acids, alkalis and salt solutions, making it suitable for equipment exposed to demanding chemical and marine environments.

Monel 400 can be supplied in a wide range of product forms, including plate, sheet, strip, bar, rod, pipe, tube, wire and forgings. It is widely used for fabricated equipment, piping systems and machined components requiring long-term corrosion resistance.

Surface Finish

Pickled / Bright / Ground / Polished / Machined

Technique

Hot Rolled / Cold Rolled / Cold Drawn / Forged / Annealed

Applications

Marine Equipment, Heat Exchangers, Chemical Processing, Pumps, Valves, Piping Systems, Oil & Gas Equipment



  • Excellent resistance to seawater

  • Good resistance to many acids and alkalis

  • Excellent resistance to chloride stress corrosion cracking

  • Good mechanical strength and toughness

  • Good performance over a broad temperature range

  • Good fabrication and forming characteristics

  • Suitable for marine and chemical environments

  • Reliable long-term corrosion performance

Chemical Composition (%)

Mechanical Properties (Typical)

Element

Composition (%)

Ni

≥ 63.0

Cu

28.0–34.0

Fe

≤ 2.50

Mn

≤ 2.00

C

≤ 0.30

Si

≤ 0.50

S

≤ 0.024


Property

Typical Value

Tensile Strength

Approx. 550 MPa

Yield Strength (0.2%)

Approx. 240 MPa

Elongation

Approx. 40%

Hardness

Approx. 110–150 HB

Density

Approx. 8.80 g/cm³

Melting Range

Approx. 1300–1350°C

Mechanical properties may vary depending on product form, dimensions, processing condition, and applicable material specification.
